MEAN WELL DR-60-12 AC TO DC DIN-RAIL POWER SUPPLY 12V 4.5Amp 54W

       PRODUCT SPECIFICATIONS:

         MEAN WELL DR-60-12 AC TO DC DIN-RAIL POWER SUPPLY 12V 4.5Amp 54W

• Model: DR-60-12

         OUTPUT

• DC Voltage: 12V
• Rated Current: 4.5A
• Current Range: 0 ~ 4.5A
• Rated Power: 54W
• Ripple & Noise (max.): 120mVp-p
• Voltage ADJ. Range: 11.1 ~ 13.2V
• Voltage Tolerance: ±1.0%
• Line Regulation: ±1.0%
• Load Regulation: ±1.0%
• Setup, Rise Time: 100ms, 20ms/230VAC     200ms, 20ms/115VAC at full Load
• Hold up Time: 100ms/230VAC     23ms/115VAC at full Load

         INPUT

• Voltage Range: 88 ~ 264VAC     124 ~ 370VDC
• Frequency Range: 47 ~ 63Hz
• Efficiency: 82%
• AC Current: 1.2A/115VAC     0.8A/230VAC
• Inrush Current: Cold Start 18A/115VAC     36A/230VAC

         PROTECTION

• Overload: 105 ~ 160% Rated Output Power
• Over Voltage: 13.8 ~ 16.2V

         Dimension

• 78*93*56 (W*H*D)

         DR-60-12 Data Sheet
