75W 0-10V CONSTANT VOLTAGE DIMMING DRIVER

       PRODUCT SPECIFICATIONS:

         75W 0-10V CONSTANT VOLTAGE DIMMING DRIVER

• Model No.: EUP75A-1H24V-1

           PRODUCT FEATURES:

• Single channel constant voltage output,3.1A Max
• Support 3-in-1 dimming mode (0/1-10V active signal, adjustable resistance and PWM signal)
• High input voltage of 220VAC ~ 240VAC
• Dimming range of 0-100%, and dimming effect smooth, no flicker
• 100% output when no dimming signal input, can be used as normal power supply.
• Overload protection; over voltage protection; short circuit protection; Over temperature
• IP20, suitable for indoor LED lighting application

           INPUT:

• Efficiency: >90%@230VAC, Full Load
• Voltage: 220VAC-240VAC
• Frequency Range (Hz): 50/60Hz
• Power Factor: ≥0.5@230VAC, Full Load
• AC Current (max): 0.9Amax@230VAC
• Inrush Current (max): Cold Start, 45A@230VAC.

           OUTPUT:

• Current (mA) / Voltage (VDC) / Power (W): 3.1A / 24VDC / 74.4W
• R&N (max): 200mVp-p
• Channel: 1
• Voltage Accuracy: ±3%

           FUNCTION:

• Dimming Type: 0/1-10V active signal, adjustable resistance, PWM
• Dimming Range: 0.1%-100% Dimming to off

           PROTECTION:

• Short Circuit: Hiccup recovers after fault condition is removed.
• Overload: Hiccup recovers after fault condition is removed
• Over Voltage: Hiccup recovers after fault condition is removed.

           OTHERS:

• Working Temperature: -20°C~50°C
• Storage Temperature., Humidity: 40°C~85°C 20-90%RH
• Tc: 90°C
• Material: Metal
• IP Rating: IP20
• Lifetime: 30000h@tc:80°C
• Dimension: 203*54*33mm (L*W*H)
