LIFUD MULTI OUTPUT CONSTANT CURRENT DRIVER 40W DALI-2 550-1050mA
- Write a review
AED26.25
Tax included
DZ40/LF-AAD040-1050-42
Secure payment
By Mamo Pay
Free Shipping
On orders above AED 200
Estimated Delivery
Dispatched within 24 hours
Guaranteed safe & secure checkout
PRODUCT SPECIFICATIONS:
LIFUD MULTI OUTPUT CONSTANT CURRENT DRIVER 40W DALI-2 550-1050mA
DESCRIPTION:
- LF-AAD040-1050-42 is a 40W constant current LED driver. It has DALI-2 dimming and push dimming functions. Its rated input voltage limit is 198-264Vac. The output current can be adjusted via the DIP switch from 550mA to 1050mA (550mA, 600mA, 650mA, 700mA, 750mA, 800mA, 850mA, 900mA, 950mA, 1000mA, 1050mA), in steps of 50mA.
Features:
- IP20
- Suitable for Class II light fixtures
- Constant current output. The output current can be adjusted via the DIP switch
- Built-in active PFC function
- Standby power consumption: ≤0.5W
- Dimming depth: 0.1%
- DALI-2 dimming function. The logarithmic dimming curve or the linear dimming curve can be selected via the software
- Push dimming function.
- 5-year warranty (Please refer to the warranty condition.)
Applications:
- Indoor office lighting
- Decorative lighting
- Commercial lighting
- Residential lighting
- Plant lighting.
SPECIFICATIONS:
| Output Type: | Constant Current |
| Output Voltage: | 9-42VDC |
| Output Current: | 550mA, 600mA, 650mA, 700mA, 750mA, 800mA, 850mA, 900mA, 950mA, 1000mA, 1050mA |
| Output Wattage: | 40W |
| Input Voltage: | 220–240 VAC
180-280 VDC |
| Input Current: | 0.3A Max |
| Connection In: | Push Terminals |
| Connection Out: | Push Terminals |
| Case Type: | Plastic Enclosed |
| Flicker Percentage: | ≤1.0% |
| Efficiency: | ≥88% |
| Power Factor: | ≥0.9 |
| Working Temp: | – 20°C ~ +45°C |
| Dimensions: | 142 x 46 x 28 mm |
| IP Rating: | IP20 |
| Warranty: | 5 Years (Tc ≤86°C) |
| Protections: | Open Circuit: <59V |
| Short Circuit: Hiccup mode (auto-recovery) | |
| Additional Features | |
| Dimmable: | Yes: DALI |
| Voltage Adjustment: | No |
| Current Adjustment: | Yes |
| Cooling Fan: | No |
LF-AAD040 Data Sheet
